Roll-Up
The roll-up system is characterized by an easy and quick to set up stand. This is covered with the single-layer laser protection curtain BC3.F1P01.1RU1. An area of (W x H) 900 x 2000 mm is covered. To connect several systems, Velcro strips are provided at the edges and the connector BC3.F1P01.1274 is required. The curtain is certified according to EN 12254.
- Order number: BC3F1P011RU1
- GTIN: 4050369018297
- Pack unit: 1 pieces
- Weight incl. packaging: 4,05 kg
Product number:
BC3F1P011RU1
Product information "Roll-Up"
The display with the single-layer laser protection material is based on the silicate fabric F1P01 and is characterized by the following points:
- Size: 900 x 2.000mm
- Connection by means of Velcro/fluff tape (Only BC3.F1P01.1RU1 in combination with BC3.F1P01.1274)
- Laser preferred direction (single-sided use)
- Ideal for low to medium laser powers
- Lightweight frame and carrying case
The instruction manual for this product can be found here.
Protection range
ultraviolett
Protection within the ultraviolet spectral range between 180 and 400nm
visible
Protection within the visible spectral range between 400 and 700nm
near infrared
Protection within the near infrared spectral range between 700nm and 1400nm
Infrared
Protection in the infrared spectral range above 1400nm
| Colour: | silver grey |
|---|---|
| Properties: | Lightweight, single-sided usable |
| Protection Class / Norm: | EN 12254 |
| Protection range: | Infrared, near infrared, ultraviolett, visible |
| WAVELENGTH (NM) | OD | OPERATING MODE / TESTED PROTECTION LEVEL |
|---|---|---|
| 180 - 315 | (OD5+) | D AB5 + IR AB3 + M AB5Y |
| >315 - 1050 | (OD5+) | DIRM AB5 |
| >1050 - 1400 | (OD5+) | DIRM AB5 |
| >1400 - 20000 | (OD3+) | DI AB3 + R AB3Y + M AB4 |
