laser safety spectacle R14T2K02L
The laservision laser safety goggle R14.T2K02.1003 with a lip seal frame (L), provides a broad band protection effect within the NIR and IR- spectral area (850-11,500nm). The OTG goggle with light grey filters without lamination can be worn over average large correction glasses. The exchangeable clip frame with lip seal lends this OTG goggles a unique and good wearing comfort. The laser safety goggle comes with a metal box, which can also be used as a storage box.
- Order number: R14T2K021003
- GTIN: 4050369019713
- Pack unit: 1 pieces
- Weight incl. packaging: 0.64 kg
- Weight excl. packaging 0.20 kg
Protection range
Infrared
Protection in the infrared spectral range above 1400nm
near infrared
Protection within the near infrared spectral range between 700nm and 1400nm
| Coating: |
no coating
|
| Filter curvature: |
Flat filter
|
| Protection Class / Norm: |
EN 207 full protection
|
| Cushion: |
Lip seal (L)
|
| Frame type: |
Goggle with strap
|
| Properties: |
No neutral glass lamination
|
| Frame: |
R14
|
| Filter: |
T2K02
|
| Filter colour: |
Light grey
|
| colour recognition: |
Excellent
|
| Filter thickness: |
ca. 4-5mm
|
| Filter material: |
Mineral glass
|
| Filter technology: |
Absorption filter
|
| Protection range: |
Infrared
near infrared |
| Visual brightness: |
Very good
|
| VLT (approx.): |
70%
|
| wavelength (nm) | OD | Operating mode / Tested protection level |
| 850 - 900 | (OD3+) | DIRM LB3 |
| >900 - 950 | (OD4+) | DIRM LB4 |
| >950 - <980 | (OD5+) | DIRM LB5 |
| 980 - <1030 | (OD7+) | D LB6 + IR LB7 + M LB7Y |
| 1030 - 1400 | (OD8+) | D LB6 + IR LB8 + M LB8Y |
| >1400 - 11500 | (OD4+) | DIR LB4 |
