laser safety magnifier F27P1P10 420mm

The laser safety magnifier F27.P1P10.1241 is, except less interruptions, certified for the wavelength range 180-11500nm acc. EN 207. It is especially characterized for its high leveled protection rating within the IR-range. Additionally it offers M-protection rating for USP lasers and an alignment protection between 640-700nm acc. to EN 208.

  • F27P1P101241
  • GTIN: 4050369023475
  • 1 pieces
  • 0.588 kg
  • 0.102 kg
The laser safety magnifier F27.P1P10.1241 with standard temples is except less...more

The laser safety magnifier F27.P1P10.1241 with standard temples is except less interruptions, certified for the wavelength range 180-11500nm acc. EN 207. It is especially characterized for its high leveled protection rating within the IR-range. When using binocular magnifiers in laser surgery, it is mandatory to take the increase of power or energy density into consideration. Only the combination of suitable laser safety filters in front of the loupe and a laser safety goggle is considered to be safe. In this case the magnifier is combined with the laser safety filter P1P10 is used at multiple medical applications. The laser safety magnifier F27 combines the proven OTG frame F22, with support of the new developed adapter, a binocular magnifier HR2.5x/420mm from one of the leading german manufacturers. The standard magnification is 2,5 at a working distance of 420mm. The filter P1P10, within the shield and also on the magnifier, features enough visual transmission and a good colour view. The wavefront optimised uvex high-res shield offers a distortion-free imaging quality and fatigue-proof seeing. Especially in combination long time wearing and corrective glasses this is highly appreciated. The goggle is shipped in a handy case with foam for a protective storage. This case also includes a professional cleasing fluid and a cord.

Technical Data

Protection range
Infrared
Infrared

Protection in the infrared spectral range above 1400nm

near infrared
near infrared

Protection within the near infrared spectral range between 700nm and 1100nm

ultraviolett
ultraviolett

Protection within the ultraviolet spectral range between 180 and 400nm

visible
visible

Protection within the visible spectral range between 400 and 700nm

Coating: Front side anti-scratch / rear side anti-fog
Filter curvature: Flat filter
Protection Class / Norm: EN 207 full protection
EN 208 Alignment protection
Cushion: No cushion
Frame type: OTG with temples
Properties: Lightweight
M-protection rating
Frame: F27
Filter: P1P10
Filter colour: Blue
colour recognition: Good
Filter thickness: ca. 2mm
Filter material: Plastic
Filter technology: Absorption filter
Protection range: Infrared
near infrared
ultraviolett
visible
Visual brightness: Sufficient
VLT (approx.): 16%
wavelength (nm) OD Operating mode  / Tested protection level
180 - 315 (OD10+) D LB10 + IR LB4 + M LB6
>315 - 385 (OD8+) D LB6 + IRM LB8
>385 - 400 (OD4+) DIRM LB4
720 - <770 (OD2+) DIRM LB2
770 - <800 (OD3+) DIRM LB3
800 - <840 (OD4+) DIRM LB4
840 - <880 (OD5+) DIRM LB5
880 - <960 (OD6+) DIRM LB6
960 - <1030 (OD7+) D LB6 + IRM LB7
1030 - 1400 (OD8+) D LB6 + IRM LB8
>1400 - 3600 (OD4+) D LB3 + I LB4 + R LB3Y
>3600 - 4800 (OD3+) DI LB3 + R LB3Y
>4800 - 11500 (OD4+) DI LB4 + R LB3Y
