laservision laser safety filter for laser safety eyewear

Absorbing materials are the common standard in order to block light of a defined wavelength range from the spectrum. As basic material special optic filter glass or plastics with special absorber dyes are mostly used. Absorption means that the light energy of the specified wavelength for which the filter is designed for is transformed to heat, when the beam hits the filter.  Each of the different materials used for absorption filters, plastics and glass, does have advantages and disadvantages with respect to protection and comfort. Both features have to taken into consideration during the selection process of the right filter.

Whereas the blocking range of interference filters depends mostly on the design of the layer structure, the blocking range of commonly used absorption filters depends on mainly on the material properties of the substrate. Because in case of a laser hit most of the laser energy is reflected from an interference filter, the protection is highly independent from the chosen substrate. Therefore it is possible to achieve this this technology the high protection levels using plastic filters which have previously only been available with glass filter technology. Often also reflective coatings are applied as an add on to absorbing glass filters to optimize the protection range or to increase the protection level of the filter.

To be able to offer all laser operators the perfect laser safety eyewear, laservision develops and manufactures, among other standard spectacles more than hundred special filters with single-CE marking per year. This results mainly out of laservision's enormous experience with the handling of different materials, as plastics, mineral glasses or endowed special glasses, as well as out of the control of the technology for combining absorption- and reflection filters.

Absorbing materials are the common standard in order to block light of a defined wavelength range from the spectrum. As basic material special optic filter glass or plastics with special... read more »
Close window
laservision laser safety filter for laser safety eyewear

Absorbing materials are the common standard in order to block light of a defined wavelength range from the spectrum. As basic material special optic filter glass or plastics with special absorber dyes are mostly used. Absorption means that the light energy of the specified wavelength for which the filter is designed for is transformed to heat, when the beam hits the filter.  Each of the different materials used for absorption filters, plastics and glass, does have advantages and disadvantages with respect to protection and comfort. Both features have to taken into consideration during the selection process of the right filter.

Whereas the blocking range of interference filters depends mostly on the design of the layer structure, the blocking range of commonly used absorption filters depends on mainly on the material properties of the substrate. Because in case of a laser hit most of the laser energy is reflected from an interference filter, the protection is highly independent from the chosen substrate. Therefore it is possible to achieve this this technology the high protection levels using plastic filters which have previously only been available with glass filter technology. Often also reflective coatings are applied as an add on to absorbing glass filters to optimize the protection range or to increase the protection level of the filter.

To be able to offer all laser operators the perfect laser safety eyewear, laservision develops and manufactures, among other standard spectacles more than hundred special filters with single-CE marking per year. This results mainly out of laservision's enormous experience with the handling of different materials, as plastics, mineral glasses or endowed special glasses, as well as out of the control of the technology for combining absorption- and reflection filters.

Close filters
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •
  •



1
10

1
10

1
10

1
10
laservision Laserschutzbrille F18P1G041001 laser safety eyewear F18P1G04
The laser safety goggle F18.P1G04.1001 is especially suitable for IR- UV and CO2-lasers at wavelength range between 180nm-400 and...
laservision Laserschutzbrille F22P1G04 laser safety eyewear F22P1G04
The laser safety goggle F22.P1G04.1001 is especially suitable for IR- UV and CO 2 -lasers at wavelength range between 180nm-400 and...
laservision Laserschutzbrille R14 mit Filter T1Q05 Laser safety eyewear R14T1Q05
The laservision Laser safety eyewear R14.T1Q05.1002 with foam frame offers full protection within the NIR and IR-range (between...
laservision Laserschutzbrille R14 mit Filter T1Q05 Laser safety eyewear R14T1Q05
The laservision Laser safety eyewear R14.T1Q05.1003 with lip seal frame offers full protection within the NIR and IR-range (between...
laservision Laserschutzbrille R01 mit Laserschutzfilter T1Q05 Laser safety eyewear R14T1Q05
The laservision Laser safety eyewear R01.T1Q05.1001 offers full protection within the NIR and IR-range (between 1025-1320nm as well as...
laservision Laserschutzbrille F18 mit Filter P1B05 laser safety spectacle F18P4B05
The laser safety goggle F18.P4B05.1001 is suitable for laser radiation within the red wavelength range and possesses full protection as...
laservision Laserschutzbrille F18 mit Filter P1B05 laser safety spectacle F22P4B05
The laser safty goggle F22.P4B05.1001 ist suitable for laser radiation within the red area and possesses full protection as well as...
laservision Laserschutzbrille F22 mit Filter P1P15 laser safety spectacle F22P1P15
The laser safety goggle F22.P1P15.1001 is suitable for almost the complete wavelength range between 180 and 14000. Within this range it...
laservision Laserschutzbrille F18 mit Filter P1P15 laser safety spectacle F18P1P15
The laser safety goggle F18.P1P15.1001 is suitable for almost the complete wavelength range range between 180 and 14000. Within this...
laser safety spectacle F20T1K04 laser safety spectacle F20T1K04
The laser safety spectacle F20.T1K04.1001 provides very high protection levels for YAG and fiber lasers within the NIR- and IR-spectral...
laser safety spectacle R01T1A02 laser safety spectacle R01T1A02
The laservision laser safety eyewear R01.T1A02.1001 is suitable to adjust lasers within the wavelength area 630-690nm. It only provides...
laservision Laserschutzbrille F22.P1L16.1001 laser safety spectacle F22P1L16
The laser safety goggle F22.P1L16.1001 with standard temples is suitableIt is especially suitable for different applications with high...
laservision Laserschutzbrille F18.P1L16.1001 laser safety spectacle F18P1L16
The laser safety goggle F18.P1L16.1001 is suitable for different applications with high power lasers in the UV, blue and green area up...
laser safety spectacle F22P1L15 laser safety spectacle F22P1L15
The laser safety goggle F22.P1L15.1001 is suitable for UV-lasers and IR-lasers within 700-1090nm as well as for powerful...
laservision Laserschutzbrille F18 mit Laserschutzfilter P1L15 laser safety spectacle F18P1L15
The laser safety goggle F18.P1L15.1001 is suitable for UV-lasers and IR-lasers within 700-1090nm as well as for powerful...
laservision Laserschutzbrille F18.P1D09 laser safety spectacle F18P1D09
The laser safety goggle F18.P1D09.1001 is suitable for Er:YAG and CO2-laser and offers full protection. The frame with flex temples fit...
laservision Laserschutzbrille F22.P1D09 laser safety spectacle F22P1D09
The laser safety goggle F22.P1D09.1001 is suitable for Er:YAG and CO2-laser and offers full protection. The frame with standard temples...
laser safety spectacle F04P1G01 laser safety spectacle F04P1G01
The laservision laser safety goggleF04.P1G01.1001 is suitable for CO 2 -laser and cw UV-laser and especially for frequent tripled Nd:YAG...
laser safety spectacle F20T2K05 laser safety spectacle F20T2K05
The laser safety spectacle F20.T2K05.1001 provides a broadband laser safety within the NIR- and IR-spectral range (850-11500nm). The...
laser safety spectacle R14T1L02 laser safety spectacle R14T1L02
The laservision laser safety goggle R14.T1L02.1003 with a lip seal frame, provides very high M-protection ratings within the UV, VIS and...
laser safety spectacle R14T1L05 laser safety spectacle R14T1L05
The laservision laser safety goggle R14.T1L05.1002 with a foam frame, provides high laser protection ratings for USP lasers within the...
laser afety spectacle R14T1L05 laser afety spectacle R14T1L05
The laservision laser safety goggle R14.T1L05.1003 with a lip seal frame, provides high laser protection ratings for USP lasers within...
laser safety spectacle R14T1M01 laser safety spectacle R14T1M01
The laservision laser safety goggle R14.T1M01.1002 with a foam frame, provides broad laser protection ratings within the UV, VIS, NIR...
laser safety spectacle R14T1M01 laser safety spectacle R14T1M01
The laservision laser safety goggle R14.T1M01.1003 with a lip seal frame, provides broad laser protection ratings within the UV, VIS,...
laser safety spectacle R14T1P01 laser safety spectacle R14T1P01
The laservision laser safety goggle R14.T1P01.1002 with a foam frame, provides a broadband laser protection effect within the UV, VIS,...
laser safety spectacle R14T1P01 laser safety spectacle R14T1P01
The laservision laser safety goggle R14.T1P01.1003 with a lip seal frame, provides a broadband laser protection effect within the UV,...
laser safety spectacle R14T1P02 laser safety spectacle R14T1P02
The laservision laser safety goggle R14.T1P02.1002 with a foam frame, provides a broadband laser protection effect within the UV, VIS,...
laser safety spectacle R14T1P04 laser safety spectacle R14T1P04
The laservision laser safety goggle R14.T1P04.1002 with a foam frame, provides an extreme broadband laser protection effect within the...
laser safety spectacle R14T1P04 laser safety spectacle R14T1P04
The laservision laser safety goggle R14.T1P04.1003 with a lip seal frame, provides an extrem broadband laser protection effect within...
laservision Laserschutzbrille R14.T1P05.1002 laser safety spectacle R14T1P05
The laservision laser safety goggle R14.T1P05.1003 is a broadband filter for high power –YAG, -fiber and disc-laser provides high...
