laser safety spectacle R01T1K01
The laservision laser safety eyewear R01.T1K01.1001 provides high protection ratings within the VIS, NIR and IR spectral range (647-1550nm; 9000-11.500nm). The full protection spectacle can be combined with an Rx-insert. The small, reinforced goggle with adjustable temples and colorless filters is characterized with a light weight and a good field of view. The shipment includes a spectacle cord and a metal box, which can also be used as its storage box.
- Order number: R01T1K011001
- GTIN: 4050369017511
- Pack unit: 1 pieces
- Weight incl. packaging: 0,44 kg
- Weight excl. packaging: 0,10 kg
Product number:
R01T1K011001
Product information "laser safety spectacle R01T1K01"
Protection range
![Icon-VIS](https://www.uvex-laservision.de/media/8e/06/4e/1664273701/Icon-VIS.png)
visible
Protection within the visible spectral range between 400 and 700nm
![Icon-NIR](https://www.uvex-laservision.de/media/e0/0a/70/1664273699/Icon-NIR.png)
near infrared
Protection within the near infrared spectral range between 700nm and 1400nm
![Icon-IR](https://www.uvex-laservision.de/media/e8/14/0a/1664273699/Icon-IR.png)
Infrared
Protection in the infrared spectral range above 1400nm
Coating: | no coating |
---|---|
Cushion: | No cushion |
Filter: | T1K01 |
Filter colour: | Green blue |
Filter curvature: | Flat filter |
Filter material: | Mineral glass |
Filter technology: | Absorption filter |
Filter thickness: | ca. 5-6mm |
Frame: | R01 |
Frame type: | Spectacle with Rx insert option |
Properties: | Adjustable temples, Neutral glass lamination |
Protection Class / Norm: | EN 207 full protection |
Protection range: | Infrared, near infrared, visible |
VLT (approx.): | 45% |
Visual brightness: | Good |
colour recognition: | Sufficient |
WAVELENGTH (NM) | OD | OPERATING MODE / TESTED PROTECTION LEVEL |
---|---|---|
620 - <640 | (OD1+) | DIRM LB1 |
640 - <647 | (OD2+) | DIRM LB2 |
647 - <670 | (OD3+) | DIRM LB3 |
670 - <685 | (OD4+) | DIRM LB4 |
685 - <690 | (OD5+) | DIRM LB5 |
770 - 1130 | (OD10+) | D LB7 + IR LB9 + M LB10 |
>1130 - 1200 | (OD9+) | D LB7 + IRM LB9 |
>1200 - 1230 | (OD8+) | D LB7 + IRM LB8 |
>1230 - 1260 | (OD7+) | DIRM LB7 |
>1400 - 1410 | (OD4+) | DI LB4 + R LB3Y + M LB3 |
>1410 - 1520 | (OD3+) | DI LB3 + R LB3Y + M LB3 |
4200 - 25000 | (OD5+) | D LB5 + I LB5Y + R LB3Y |
