laser safety spectacle F47P1M03
The laser safety spectacle F47.P1M03.1001 with the gray filter is certified with a few interruptions for the wavelength range from 180-14000nm according to EN 207 (full protection) is especially suitable for medical lasers, for combination lasers around 1064nm, for CO2 lasers, Nd: YAG, disk and fiber lasers and in the NIR range. It also has M protection levels for ultra-short laser pulses. The light, sporty 2-lens eyewear with low weight and base curve 8 has good visual brightness and a daylight transmission (VLT) of approx. 25%. The laser safety spectacle can be supplemented with a special adapter from laservision with an LED light or a magnifying glass. laservision recommends the professional cleaning station (A99.CLSTA.1300) for cleaning the laser safety eyewear.
- Order number: F47P1M031001
- GTIN: 4050369057296
- Pack unit: 1 pieces
- Weight incl. packaging: 0.23 kg
- Weight excl. packaging 0.03 kg
Protection in the infrared spectral range above 1400nm
Protection within the near infrared spectral range between 700nm and 1400nm
Protection within the ultraviolet spectral range between 180 and 400nm
| Coating: |
no coating
|
| Filter curvature: |
Base curve 8
|
| Protection Class / Norm: |
EN 207 full protection
|
| Cushion: |
No cushion
|
| Frame type: |
Spectacle
|
| Properties: |
2-Komponenten-Softbügel
Anpassbare Nasenauflage Lightweight M-protection rating |
| Frame: |
F47
|
| Filter: |
P1M03
|
| Filter colour: |
Grey
|
| colour recognition: |
Very good
|
| Filter thickness: |
ca. 2mm
|
| Filter material: |
Plastic
|
| Filter technology: |
Absorption filter
|
| Protection range: |
Infrared
near infrared ultraviolett |
| Visual brightness: |
Good
|
| VLT (approx.): |
25%
|
| wavelength (nm) | OD | Operating mode / Tested protection level |
| 180 - 315 | (OD10+) | D LB10 + IR LB4 + M LB6Y |
| >315 - 375 | (OD8+) | D LB6 + IR LB8 + M LB8Y |
| >375 - 385 | (OD3+) | DIRM LB3 |
| 1020 - <1030 | (OD6+) | DIRM LB6 |
| 1030 - <1040 | (OD7+) | D LB6 + IRM LB7 |
| 1040 - 1064 | (OD8+) | D LB6 + IR LB8 + M LB8Y |
| >1064 - 1073 | (OD7+) | D LB6 + IRM LB7 |
| >1073 - 1083 | (OD6+) | DIRM LB6 |
| >1083 - 1090 | (OD5+) | DIRM LB5 |
| 1090 - 1100 | (OD4+) | DIRM LB4 |
| 1400 - <1600 | (OD2+) | DIRM LB2 |
| 1600 - <1750 | (OD3+) | DIM LB3 + R LB3Y |
| 1750 - 3000 | (OD4+) | DIM LB4 + R LB3Y |
| >3000 - <5400 | (OD2+) | DIRM LB2 |
| 5400 - 14000 | (OD6+) | DI LB4 + R LB3Y + M LB5Y |
